仪器简介：

YL -6615B模拟运输振动试验朹�/strong> Simulation Transport Vibration Test Machine

用途：本机适用于玩具、电子、家具、礼品、陶瓷、包装等产品进行模拟运输测试，符合美国及欧洲运输标准，具有振动顺畅、噪音低、结构合理、牢固耐用等特点。　　

依据标准� EN、ANSI、UL、ASTM、ISTA国际运输标准�

Use: This machine was applicable to toys� electronics� furniture� gifts� ceramics� packaging and other products to simulate the transport tests. Comply with the U.S. and European transport standards and have characteristic with low noise� reasonable structure� durable� etc.

Basic Standard : Following The EN、ANSI、UL、ASTM、ISTA International Transport Standard

　　　　　　　　　　　　　　　　　　　　　　　　

技术参数：

规格Specification�

振动频率 Oscillation Frequency 100~300rpm/min，可设定 Adjustable

� � Amplitude 25mm

振动方式 Vibration Mode 回转振动（垂直） Rotary Vibration (Vertical)

**载重 Max Load 60kg

数显频率精度Digital Display Precision 0~999H99M

机台动力 Equipment Power AC变频马达 AC Invertors Motor

机台结构 Equipment Structure 防振脚垫，铝型材调整固定架，美观

Anti-Vibration Pads� Aluminum Adjustment Holder � Aesthetic.

有效工作台面尺寸 Effective Work Table Size 1000��1000mm

**外形尺寸 Max Outside Measurement 132��110��81(W��D��H)cm

重量 Weight �?00kg About300kg

主要特点９�/strong>

YL -6615B模拟运输振动试验朹�/strong> Simulation Transport Vibration Test Machine

用途：本机适用于玩具、电子、家具、礼品、陶瓷、包装等产品进行模拟运输测试，符合美国及欧洲运输标准，具有振动顺畅、噪音低、结构合理、牢固耐用等特点。　　

依据标准� EN、ANSI、UL、ASTM、ISTA国际运输标准�

Use: This machine was applicable to toys� electronics� furniture� gifts� ceramics� packaging and other products to simulate the transport tests. Comply with the U.S. and European transport standards and have characteristic with low noise� reasonable structure� durable� etc.

Basic Standard : Following The EN、ANSI、UL、ASTM、ISTA International Transport Standard
