作为市场上高端科研级荧光光谱仪的领导厂商，IBphotonics公司一直致力于在已有技术优势的基础上，不断创新，结合用户不断升级的实验需求，将我们的系列仪器持续完善，增加更多样性的功能模块，丰富用户的选择，更好地服务于所有荧光光谱用户的实验工作、/p>
KEY FEATURES
Emission time-resolved measurements in
solutions vapor cells and thin films＋/strong>
Fluorescence anisotropy measurements＋/strong>
Optimized for MHz Ti:Sa Oscilators＋/strong>
Covers fluorescence phenomena from
femtoseconds to 2 ns＋/strong>
Sub-100fs time resolution＋/strong>
Easy alignment.
DetectionRange: |
320-1300nm; |
Excitation: |
SHG; |
Time Resolution: |
< 100fs (for laser pulsewidth <70fs) |
Optical Delay: |
2-ns travel 3 fs step; 4ns optional |
Dark Count Rate: |
3.106cps |
Software: |
Standalone and LabView TM |
Dimentions: |
90 x 70 x 18.5cm (35.4 x 27.5 x 7.3 in.) |
Input Parameters |
|
Pulse Energy: |
>3 nJ (>230mW@76MHz) |
Pulsewidth: |
30 - 200 fs |
Beam Diameter: |
2 - 5 mm Near TEM00 |
Polarization: |
Linear Horizontal |
Repetition rate: |
1-200 MHz |
Wavelenght: |
770-820 nm |
Beam height: |
110 mm |
