Remarks:

1. All the typical values are based on the 1.6mm specimen. Test method is according to IPC-TM-650.

2.All the typical values listed above are for your reference only and not intended for specification. Please contact Shengyi Technology Co., Ltd. for detailed information. All rights from this data sheet are reserved by Shengyi Technology Co., Ltd.

Explanation: C=Humidity conditioning, D=Immersion conditioning in distilled water, E=Temperature conditioning

The first digit following the letter indicates the duration of preconditioning in hours, the second digit the preconditioning temperature in � and the third digit the relative humidity.

Items	Method	Condition	Unit	Typical Value
Tg	2.4.24.4	DMA	ℂ�/td>	185
	2.4.25D	DSC		180
Td	2.4.24.6	5% wt. loss	ℂ�/td>	355
T288	2.4.24.1	TMA	min	30
T260	2.4.24.1	TMA	min	60
Thermal Stress	2.4.13.1	288�? solder dip	-	>100s No Delamination
CTE (Z-axis)	2.4.24	Before Tg	ppm/ℂ�/td>	40
		After Tg	ppm/ℂ�/td>	210
		50-260ℂ�/td>	%	2.4
Dissipation Constant (1MHz)	2.5.5.9	C-24/23/50	-	4.9
Dissipation Factor (1MHz)	2.5.5.9	C-24/23/50	-	0.018
Volume Resistivity	2.5.17.1	C-96/35/90	MΩ.cm	8.12×108
Surface Resistivity	2.5.17.1	C-96/35/90	MΩ	2.65×107
Arc Resistance	2.5.1	D-48/50+D-0.5/23	s	135
Dielectric Breakdown	2.5.6	D-48/50+D-0.5/23	kV	45+kV NB
Peel Strength (1Oz)	2.4.8	288�?10s	N/mm	1.4
Flexural Strength(LW/CW)	2.4.4	A	MPa	560/440
Water Absorption	2.6.2.1	E-1/105+D-24/23	%	0.08
Flammability	UL94	C-48/23/50	Rating	V-0
CTI	IEC60112	A	Rating	PLC 3
