产品性能９�/p>

Items		Method	Condition	Unit	Typical Value
CTE (Z-axis)		IPC-TM-650 2.4.24	Before Tg	ppm/ℂ�/td>	–�/td>
			After Tg	ppm/ℂ�/td>	–�/td>
			50-260ℂ�/td>	%	6.5
T260		IPC-TM-650 2.4.24.1	TMA	min	5
Thermal Stress		IPC-TM-650 2.4.13.1	288�? solder dip	--	30S No delamination
Volume Resistivity		IPC-TM-650 2.5.17.1	After moisture resistance	MΩ.cm	5.3 x 108
			E-24/125	MΩ.cm	3.1 x 105
Surface Resistivity		IPC-TM-650 2.5.17.1	After moisture resistance	MΩ	7.1 x 107
			E-24/125	MΩ	6.3 x 106
Arc Resistance		IPC-TM-650 2.5.1	D-48/50+D-4/23	s	120
Dielectric Breakdown		IPC-TM-650 2.5.6	D-48/50+D-4/23	kV	45+kV NB
Dissipation Constant (Dk)		IPC-TM-650 2.5.5.9	1MHz	--	4.5
		IEC 61189-2-721	10GHz	--	–�/td>
Dissipation Factor (Df)		IPC-TM-650 2.5.5.9	1MHz	--	0.021
		IEC 61189-2-721	10GHz	--	–�/td>
Peel Strength(1Oz HTE copper foil)		IPC-TM-650 2.4.8	A	N/mm	–�/td>
			After thermal Stress 288�?10s	N/mm	1.8
			125ℂ�/td>	N/mm	1.6
Flexural Strength	LW	IPC-TM-650 2.4.4	A	MPa	400
	CW	IPC-TM-650 2.4.4	A	MPa	350
Water Absorption		IPC-TM-650 2.6.2.1	E-1/105+D-24/23	%	0.13
CTI		IEC60112	A	Rating	PLC 0
Flammability		UL94	C-48/23/50	Rating	V-0
			E-24/125	Rating	V-0

Remarks:

1. Specification sheet: IPC-4101/30 , is for your reference only.

2. All the typical value is based on the 1.6mm specimen.

3.All the typical values listed above are for your reference only and not intended for specification. Please contact Shengyi Technology Co., Ltd. for detailed information. All rights from this data sheet are reserved by Shengyi Technology Co., Ltd.

Explanation: C=Humidity conditioning, D=Immersion conditioning in distilled water, E=Temperature conditioning

The first digit following the letter indicates the duration of preconditioning in hours, the second digit the preconditioning temperature in � and the third digit the relative humidity.
