ANTAUS-10W-2u/5M

ANTAUS-12W-6u/2M

ANTAUS-20W-20u/1M

Pulse duration* (FWHM)

<250 fs

Central wavelength** (fixed)

1030��5 nm

Average output power

>10 W

>12 W

>20 W

Pulse energy

>2 uJ

>6 uJ

>20 uJ

Pulse repetition rate***

1...5 MHz (user-adjustable)

2 MHz (fixed)

1 MHz (fixed)

Modulation of repetition rate by built-in pulse selector (optional)

single-shot...2 MHz

single-shot...2 MHz

single-shot...1 MHz

Dense-burst mode (~20 ns between pulses)

up to 6 pulses

n/a

n/a

Total energy per burst

up to 12 uJ

-

-

Spatial mode

TEM00

Polarization

linear� vertical

Output type

free-space

M^2

<1.2

Long-term stability

<1% rms (12 hours)

Optical unit dimensions (LxWxH)

341x172x115 mm

350x270x130 mm

350x270x130 mm

Control unit dimensions (LxWxH)

450x315x140 mm

450x315x140 mm

450x315x140 mm

* - pulse duration tuning to several ps upon request;

** - 1040 or 1050 nm upon request;

*** - without pulse slicer or with the pulse slicer bypassed.
