2微米宽带光源ASE 2 m Broadband Light Sources
Amplified spontaneous emission (ASE) also called superluminescence is the emission of fluorescence that is amplified along the gain medium. AdValue Photonics near 2 micron ASE source exhibits broad bandwidth with excellent spatial coherence and low temporal coherence.
Applications:
Optical component testing
Gas analysis
Biomedical analysis
Spectroscopy
Research & development
Features:
Broadest bandwidth
High output power
Near diffraction limited beam quality
Turn-key system with no maintenance required
AP-ASE-2000 |
AP-ASE-2100 |
AP-SC-MIR |
||
输出模式 |
CW |
CW |
CW |
|
输出波长 |
1.950.03 m |
2.070.02 m |
~ 1.9 to 2.4 m |
|
输出功率 |
20 mW |
10 mW |
100 mW |
|
带宽(-20dB) |
>170 nm |
>100 nm |
>500 nm ＇span>10dB bandwidtheachwave（/span> |
|
功率稳定?/span> |
5% (at 25C) |
|||
光束质量 M2 |
< 1.1 |
|||
输出偏振 |
随机偏振(eachwave可定制线偏振) |
随机偏振 |
随机偏振 |
|
输出 |
SMF-28 single mode fiber 3 mm jacket 1 m length FC/APC connector |
SMF-28 single mode fiber 3 mm jacket 1 m length FC/APC connector |
SMF-28 single mode fiber 1 m length 3 mm jacket FC/APC connector |
|
