600系列冷却式科研数字红外相朹/strong>
QSI 600系列是在500系列基础上升级而来，高?MHz双重读取频率，高速USB2.0?6位的输出是的QSI600系列具备了高成像质量和高速等优异性能、/span>
高动态范围，线性度高且噪声低，2级TEC制冷可控?5度的高温，选择液态交换式探测头可?0度、/span>
QSI600系列?种不同的型号，使用了Truesense 和Sony黑白和single-shot 彩色科研?.2mp CCD，多种型号和配置选择满足医疗、天文、工业等特殊应用、/span>
产品特点９/span>
优秀的成像质野/span>高达12mp的CCD传感?/span>
紧凑精良的设讠/span>高达8MHZ双重读取频率
高逞/span>USB2.0?6位输凹/span>可达50度的空气和液体冷即/span>
5-8个滤光片佌/span>人性化软件界面
适用亍/span>Windows?/span>Linux操作系统
产品型号９/span>
Monochrome Models |
Standard CCD |
~Pixels |
CCD Type |
Electronic Shutter |
Mechanical Shutter |
Shutter &Filter Wheel |
Shutter CFW & Guider Port |
6120 |
Sony ICX834 |
12.0M |
Interline |
6120i |
6120s |
6120ws6120ws-8 |
6120wsg6120wsg-8 |
690 |
Sony ICX814 |
9.2M |
Interline |
690i |
690s |
690ws690ws-8 |
690wsg690wsg-8 |
683 |
KAF-8300 |
8.3M |
Full frame |
‒/span> |
683s |
683ws683ws-8 |
683wsg683wsg-8 |
660 |
Sony ICX694 |
6.1M |
Interline |
660i |
660s |
660ws660ws-8 |
660wsg660wsg-8 |
640 |
KAI-04022 |
4.2M |
Interline |
640i |
640s |
640ws640ws-8 |
640wsg640wsg-8 |
632 |
KAF-3200ME |
3.2M |
Full frame |
‒/span> |
632s |
632ws632ws-8 |
632wsg632wsg-8 |
628 |
Sony ICX674 |
2.8M |
Interline |
628i |
628s |
628ws628ws-8 |
628wsg628wsg-8 |
620 |
KAI-2020M |
2.0M |
Interline |
620i |
620s |
620ws620ws-8 |
620wsg620wsg-8 |
616 |
KAF-1603ME |
1.6M |
Full frame |
‒/span> |
616s |
616ws616ws-8 |
616wsg616wsg-8 |
604 |
KAF-402ME |
400K |
Full frame |
‒/span> |
604s |
604ws604ws-8 |
604wsg604wsg-8 |
Single Shot Color Models |
Standard CCD |
~Pixels |
CCD Type |
Electronic Shutter |
Mechanical Shutter |
Shutter &Guider Port |
683c |
KAF-8300C |
8.3M |
Full frameRGB bayer filter |
‒/span> |
683cs |
683csg |
640c |
KAI-04022C |
4.2M |
InterlineRGB bayer filter |
640ci |
640cs |
640csg |
620c |
KAI-2020CM |
2.0M |
InterlineRGB bayer filter |
620ci |
620cs |
620csg |
详细型号参数９/span>
CameraModel |
Standard CCD |
CCD Type |
~Pixels |
Pixel Array |
CCD Size |
PixelSize |
Color Filter Wheel |
Guider Port |
Body Size |
6120i |
ICX814 |
Interline |
12.0M |
4250x2838 |
13.2 x 8.8mm |
3.1m |
‒/span> |
‒/span> |
Slim |
6120s |
ICX814 |
Interline |
12.0M |
4250x2838 |
13.2 x 8.8mm |
3.1m |
‒/span> |
‒/span> |
Medium |
6120ws |
ICX814 |
Interline |
12.0M |
4250x2838 |
13.2 x 8.8mm |
3.1m |
5-pos |
‒/span> |
Full |
6120wsg |
ICX814 |
Interline |
12.0M |
4250x2838 |
13.2 x 8.8mm |
3.1m |
5-pos |
◎/span> |
WSG-8 |
6120ws-8 |
ICX814 |
Interline |
12.0M |
4250x2838 |
13.2 x 8.8mm |
3.1m |
8-pos |
‒/span> |
Full |
6120wsg-8 |
ICX814 |
Interline |
12.0M |
4250x2838 |
13.2 x 8.8mm |
3.1m |
8-pos |
◎/span> |
WSG-8 |
690i |
ICX814 |
Interline |
9.2M |
3388x2712 |
12.48 x 9.98mm |
3.69m |
‒/span> |
‒/span> |
Slim |
690s |
ICX814 |
Interline |
9.2M |
3388x2712 |
12.48 x 9.98mm |
3.69m |
‒/span> |
‒/span> |
Medium |
690ws |
ICX814 |
Interline |
9.2M |
3388x2712 |
12.48 x 9.98mm |
3.69m |
5-pos |
‒/span> |
Full |
690wsg |
ICX814 |
Interline |
9.2M |
3388x2712 |
12.48 x 9.98mm |
3.69m |
5-pos |
◎/span> |
WSG-8 |
690ws-8 |
ICX814 |
Interline |
9.2M |
3388x2712 |
12.48 x 9.98mm |
3.69m |
8-pos |
‒/span> |
Full |
690wsg-8 |
ICX814 |
Interline |
9.2M |
3388x2712 |
12.48 x 9.98mm |
3.69m |
8-pos |
◎/span> |
WSG-8 |
683s |
KAF-8300 |
Full frame |
8.3M |
3326 x 2604 |
17.96 x 13.52mm |
5.4m |
‒/span> |
‒/span> |
Medium |
683ws |
KAF-8300 |
Full frame |
8.3M |
3326 x 2604 |
17.96 x 13.52mm |
5.4m |
5-pos |
‒/span> |
Full |
683wsg |
KAF-8300 |
Full frame |
8.3M |
3326 x 2604 |
17.96 x 13.52mm |
5.4m |
5-pos |
◎/span> |
WSG |
683ws-8 |
KAF-8300 |
Full frame |
8.3M |
3326 x 2604 |
17.96 x 13.52mm |
5.4m |
8-pos |
‒/span> |
Full-8 |
683wsg-8 |
KAF-8300 |
Full frame |
8.3M |
3326 x 2604 |
17.96 x 13.52mm |
5.4m |
8-pos |
◎/span> |
WSG-8 |
660i |
ICX694 |
Interline |
6.1M |
2758x2208 |
12.48 x 9.98mm |
4.54m |
‒/span> |
‒/span> |
Slim |
660s |
ICX694 |
Interline |
6.1M |
2758x2208 |
12.48 x 9.98mm |
4.54m |
‒/span> |
‒/span> |
Medium |
660ws |
ICX694 |
Interline |
6.1M |
2758x2208 |
12.48 x 9.98mm |
4.54m |
5-pos |
‒/span> |
Full |
660wsg |
ICX694 |
Interline |
6.1M |
2758x2208 |
12.48 x 9.98mm |
4.54m |
5-pos |
◎/span> |
WSG-8 |
660ws-8 |
ICX694 |
Interline |
6.1M |
2758x2208 |
12.48 x 9.98mm |
4.54m |
8-pos |
‒/span> |
Full |
660wsg-8 |
ICX694 |
Interline |
6.1M |
2758x2208 |
12.48 x 9.98mm |
4.54m |
8-pos |
◎/span> |
WSG-8 |
640i |
KAI-04022 |
Interline |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
‒/span> |
‒/span> |
Slim |
640s |
KAI-04022 |
Interline |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
‒/span> |
‒/span> |
Medium |
640ws |
KAI-04022 |
Interline |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
5-pos |
‒/span> |
Full |
640wsg |
KAI-04022 |
Interline |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
5-pos |
◎/span> |
WSG-8 |
640ws-8 |
KAI-04022 |
Interline |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
8-pos |
‒/span> |
Full |
640wsg-8 |
KAI-04022 |
Interline |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
8-pos |
◎/span> |
WSG-8 |
632s |
KAF-3200ME |
Full frame |
3.2M |
2184 x 1472 |
14.85 x 10.26mm |
6.8m |
‒/span> |
‒/span> |
Medium |
632ws |
KAF-3200ME |
Full frame |
3.2M |
2184 x 1472 |
14.85 x 10.26mm |
6.8m |
5-pos |
‒/span> |
Full |
632wsg |
KAF-3200ME |
Full frame |
3.2M |
2184 x 1472 |
14.85 x 10.26mm |
6.8m |
5-pos |
◎/span> |
WSG |
632ws-8 |
KAF-3200ME |
Full frame |
3.2M |
2184 x 1472 |
14.85 x 10.26mm |
6.8m |
8-pos |
‒/span> |
Full-8 |
632wsg-8 |
KAF-3200ME |
Full frame |
3.2M |
2184 x 1472 |
14.85 x 10.26mm |
6.8m |
8-pos |
◎/span> |
WSG-8 |
628i |
KAI-2020M |
Interline |
2.8M |
1940x1460 |
8.81 x 6.63mm |
4.54m |
‒/span> |
‒/span> |
Slim |
628s |
KAI-2020M |
Interline |
2.8M |
1940x1460 |
8.81 x 6.63mm |
4.54m |
‒/span> |
‒/span> |
Medium |
628ws |
KAI-2020M |
Interline |
2.8M |
1940x1460 |
8.81 x 6.63mm |
4.54m |
5-pos |
‒/span> |
Full |
628wsg |
KAI-2020M |
Interline |
2.8M |
1940x1460 |
8.81 x 6.63mm |
4.54m |
5-pos |
◎/span> |
WSG |
628ws-8 |
KAI-2020M |
Interline |
2.8M |
1940x1460 |
8.81 x 6.63mm |
4.54m |
8-pos |
‒/span> |
Full-8 |
628wsg-8 |
KAI-2020M |
Interline |
2.8M |
1940x1460 |
8.81 x 6.63mm |
4.54m |
8-pos |
◎/span> |
WSG-8 |
620i |
KAI-2020M |
Interline |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
‒/span> |
‒/span> |
Slim |
620s |
KAI-2020M |
Interline |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
‒/span> |
‒/span> |
Medium |
620ws-8 |
KAI-2020M |
Interline |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
5-pos |
‒/span> |
Full |
620wsg-8 |
KAI-2020M |
Interline |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
5-pos |
◎/span> |
WSG |
620ws-8 |
KAI-2020M |
Interline |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
8-pos |
‒/span> |
Full-8 |
620wsg-8 |
KAI-2020M |
Interline |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
8-pos |
◎/span> |
WSG-8 |
616s |
KAF-1603ME |
Full frame |
1.6M |
1536 x 1024 |
13.8 x 9.2mm |
9m |
‒/span> |
‒/span> |
Medium |
616ws |
KAF-1603ME |
Full frame |
1.6M |
1536 x 1024 |
13.8 x 9.2mm |
9m |
5-pos |
‒/span> |
Full |
616wsg |
KAF-1603ME |
Full frame |
1.6M |
1536 x 1024 |
13.8 x 9.2mm |
9m |
5-pos |
◎/span> |
WSG |
616ws-8 |
KAF-1603ME |
Full frame |
1.6M |
1536 x 1024 |
13.8 x 9.2mm |
9m |
8-pos |
‒/span> |
Full-8 |
616wsg-8 |
KAF-1603ME |
Full frame |
1.6M |
1536 x 1024 |
13.8 x 9.2mm |
9m |
8-pos |
◎/span> |
WSG-8 |
604s |
KAF-0402ME |
Full frame |
400K |
768 x 512 |
6.91 x 4.6mm |
9m |
‒/span> |
‒/span> |
Medium |
604ws |
KAF-0402ME |
Full frame |
400K |
768 x 512 |
6.91 x 4.6mm |
9m |
5-pos |
‒/span> |
Full |
604wsg |
KAF-0402ME |
Full frame |
400K |
768 x 512 |
6.91 x 4.6mm |
9m |
5-pos |
◎/span> |
WSG |
604ws-8 |
KAF-0402ME |
Full frame |
400K |
768 x 512 |
6.91 x 4.6mm |
9m |
8-pos |
‒/span> |
Full-8 |
604wsg-8 |
KAF-0402ME |
Full frame |
400K |
768 x 512 |
6.91 x 4.6mm |
9m |
8-pos |
◎/span> |
WSG-8 |
683cs |
KAF-8300 |
Full framecolor RGB |
8.3M |
3326 x 2604 |
17.96 x 13.52mm |
5.4m |
‒/span> |
‒/span> |
Medium |
683csg |
KAF-8300 |
Full framecolor RGB |
8.3M |
3326 x 2604 |
17.96 x 13.52mm |
5.4m |
◊/span> |
◎/span> |
WSG |
640ci |
KAI-04022 |
Interlinecolor RGB |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
‒/span> |
‒/span> |
Slim |
640cs |
KAI-04022 |
Interlinecolor RGB |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
‒/span> |
‒/span> |
Medium |
640csg |
KAI-04022 |
Interlinecolor RGB |
4.2M |
2048x2048 |
15.15 x 15.15mm |
7.4m |
◊/span> |
◎/span> |
WSG |
620ci |
KAI-2020CM |
Interlinecolor RGB |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
‒/span> |
‒/span> |
Slim |
620cs |
KAI-2020CM |
Interlinecolor RGB |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
‒/span> |
‒/span> |
Medium |
620csg |
KAI-2020CM |
Interlinecolor RGB |
2.0M |
1600 x1200 |
11.84 x 8.88mm |
7.4m |
◊/span> |
◎/span> |
WS |
◎/span>=Included Feature |
◊/span>=Optional |
‒/span>=Not available |
QSI 600 Series - Body Comparison(Click camera model to jump to that product page)
Slim Body |
Medium Size Body |
Full Size Body |
WSG Body |
|
Shutter |
Electronic |
Mechanical |
Mechanical |
Mechanical |
Exposure range |
100 sec (0.0001) to 240 min |
0.03 seconds to 240 min |
0.03 seconds to 240 min |
0.03 seconds to 240 min |
Internal Color Filter Wheel |
No |
No |
Yes 5-positionUpgradeable to 8-position |
Yes 5-positionUpgradeable to 8-position |
Integrated Guider Port |
No |
No |
No |
Yes |
Dimensions |
W4.45 x H4.45 x D1.68“/span>(add 0.23" for std T-Mount) |
W4.45 x H4.45 x D2.00“/span>(add 0.23" for std T-Mount) |
W4.45 x H4.45 x D2.5“/span>(add 0.23" for std T-Mount) |
W4.45 x H4.45 x D3.08“/span>(add 0.23" for std T-Mount)(add 0.35" for 2.156" adapter) |
Weight |
26 oz. / 740g |
34 oz. / 950g |
40 oz. / 1120g |
46 oz. / 1300g |
Back Focus |
0.61 with T-Mount adapter |
0.90 with T-Mount adapter |
1.40 with T Mount adapter |
2.10 with 2.156" thread adapter |
0.68 with C-Mount adapter |
0.68 with C-Mount adapter |
1.18 with C-Mount adapter |
1.98 with T-Mount adapter |
|
0.39 w/o mounting adapter |
0.68 w/o mounting adapter |
1.18 w/o mounting adapter |
1.76 w/o mounting adapter |
|
Camera Models |
620i620ci640i640ci628i660i690i6120i | 604s620s616s620cs632s640s683s640cs683cs628s 660s 690s 6120s | 604ws620ws616ws640ws632ws 683ws628ws 660ws 690ws 6120ws | 604wsg620wsg616wsg620csg632wsg640wsg683wsg640csg683csg628wsg 660wsg 690wsg 6120wsg |
Specifications are subject to change. Refer to product pages for complete specifications
Full-8 Body |
WSG-8 Body |
|
Shutter |
Mechanical |
Mechanical |
Exposure range |
0.03 seconds to 240 min |
0.03 seconds to 240 min |
Internal Color Filter Wheel |
Yes 8-position |
Yes 8-position |
Integrated Guider Port |
No |
Yes |
Dimensions |
W5.86 x H5.56 x D2.5“/span>including adapter plate(add 0.23" for std T-Mount) |
W5.86 x H5.56 x D3.08“/span>including adapter plate(add 0.23" for std T-Mount)(add 0.35" for 2.156" adapter) |
Weight |
51 oz. / 1450g |
56 oz. / 1600g |
Back Focus |
1.40 with T Mount adapter |
2.10 with 2.156" thread adapter |
1.18 with C-Mount adapter |
1.98 with T-Mount adapter |
|
1.18 w/o mounting adapter |
1.76 w/o mounting adapter |
|
Camera Models |
604ws-8620ws-8616ws-8640ws-8632ws-8628ws-8683ws-8660ws-8 690ws-8 6120ws-8 | 604wsg-8620wsg-8616wsg-8640wsg-8632wsg-8628wsg-8683wsg-8660wsg-8 690wsg-8 6120wsg-8 |
