倾翻载荷 Tipping load(kg)

1000

铲斗容量 Bucket capacity(m3)

0.25-0.4

机器操纵质量 Operationg weight(kg)

2200

行驶速度 Max. travel speed(km/h)

12

工作流量 Hydraulic pump flow(L/min)

75

油箱容量 Fuel tank capacity(L)

50

轮胎型号 Tires

27*8.5-15-8NHS

整车尺寸 Overall dimensions(mm)

2900×2000×1300

整机参数 Dimensions

**操作高度 Height at maximum extension(mm)

3300

铰接销高度 Height to bucket hinge pin(mm)

2725

带斗宽度 Width with bucket(mm)

1300

轮距 Track width(mm)

1080

轴距 Wheelbase(mm)

891

离地高度 Ground clearance(mm)

150

倾倒角 Dump angle

40°

倾倒高� Dumping height(mm)

2050

倾倒前� Maximum reach(mm)

790

接近� Rollback at ground

26°

离去� Angle of departure

20°

发动� Engine

型号 Maker/Model

490

功率转� Net power

55hp/2600rpm

类型 Type

直喷直列水冷四冲程柴油机

4Cylinder in-line, Water cooled, 4 stroke, Diesel engine

排量 Displacement(L)

2.156

标准配置 Standard

?标准铲斗 Standard bucket

封闭驾驶宣�/p>

液压伺服手动控制 Hydraulic joystick controls

辅具输出装置 Auxiliary hydraulic couplers

可选配� Optional

低温起动装置

Prehest starting assist system for extreme cold weather

内置暖风

Cab fitted with a heater as standard
