WX卧式旋压制粒朹/div>
报价９span>面议
| 品牌９/td> | 般匠机械 |
| 产地９/td> | 江苏 |
| 关注度： | 1382 |
| 型号９/td> | WX卧式旋压制粒朹/td> |
核心参数
螺杆数：其他
展位推荐
更多
产品介绍
一．设备概述（（/strong>
本机是一种将潮湿粉体混合料，在制粒机旋压滚轮挤压下，径向通过筛网挤出合格颗粒的一种专用设备 该专用设备主要适用于医药，化工，食品，等行业中制造各种规格的颗粒，成品经干燥后可制成各种制品。This machine is a kind of special equipment that extrudes the wet powder mixture through the screen radially through the screen under the extrusion of the spinning roller of the granulator. This special equipment is mainly suitable for the manufacture of various specifications of particles in the pharmaceutical, chemical, food, and other industries. The finished product can be made into various products after being dried.
二．设备特点＇/strong>Features （/span>
1本机抛弃以往旋转制粒机采用铸造桨叶挤压的形式，采?/strong>活动滚轮，减少造粒网的摩擦增加其寿命，同时滚轮转动压出物料使物料更加紧密、/strong>1 This machine abandons the previous rotary granulator and adopts the form of casting blade extrusion. It adopts movable rollers to reduce the friction of the granulating net and increase its life. At the same time, the rollers rotate to extrude the materials to make the materials more compact.
2本机采用加厚型特殊工艺造粒网，不使用传统冲孔网，筛网寿命大大延长，对于容易造粒的物料寿命可达一年，造粒网有整体式和抱箍式两种。本机采用水平螺旋喂料至滚轮挤压出颗粒的，再由铲刀根据物料颗粒的要求设置铲料距离从而下料。和传统的旋转制粒机相比，清洗可以直接用高压水枪清洗，方便简单而不会出现传动轴承应为进水而出现锈死的情况、/strong>加料口与各制粒装置的结构是依据安装，清洗，调整，使用方便的原则设计，各方面与物料接触部件均为优秀不锈钢制成，杜绝污染，保证了制品的清洁卫生，符合GMP咋/strong>FDA要求? This machine adopts a thickened special process granulation mesh, without using traditional punching mesh, the life of the screen is greatly extended, and the life of the material that is easy to granulate can be up to one year. The granulation mesh has two types: integral type and hoop type. . This machine adopts horizontal screw feeding to the roller to squeeze out the particles, and then the shovel blade sets the shovel distance according to the requirements of the material particles to discharge the material. Compared with the traditional rotary granulator, the cleaning can be directly cleaned with a high-pressure water gun, which is convenient and simple and will not cause the transmission bearing to be rusted due to water ingress. The structure of the
feeding port and each granulating device is designed according to the principle of installation, cleaning, adjustment, and convenient use. All parts in contact with the material are made of excellent stainless steel to prevent pollution and ensure the cleanliness of the product. It is in line with GMP and FDA. Claim.
技术参数（Technical Parameters（/strong>
| 型号Model | WX-160 | WX-300 | WX-350 | WX-500 |
| 制粒直径 Granulating Size(mm) | 0.5-5 | 0.5-5 | 0.5-10 | 0.5-10 |
| 重量 Weight(kg) | 140 | 550 | 850 | 1700 |
| 电机功率 Power(KW) | 2.2 | 7.5 | 11 | 22 |
| 生产能力 Capacity(kg/h) | 30-140 | 120-800 | 250-1050 | 650-1800 |
| 外形尺寸Overall Size(mm) | 650×480×800 | 900×580×1100 | 1100*750*1200 | 1500*1000*1350 |
问商宵/div>
- WX卧式旋压制粒机的工作原理介绍＞/li>
- WX卧式旋压制粒机的使用方法＞/li>
- WX卧式旋压制粒机多少钱一台？
- WX卧式旋压制粒机使用的注意事项
- WX卧式旋压制粒机的说明书有吗？
- WX卧式旋压制粒机的操作规程有吗＞/li>
- WX卧式旋压制粒机的报价含票含运费吗＞/li>
- WX卧式旋压制粒机有现货吗？
- WX卧式旋压制粒机包安装吗？
江阴市般匠机械制造有限公司为您提供般匠机械WX卧式旋压制粒机，WX卧式旋压制粒机产地为江苏，属于造粒机，除了WX卧式旋压制粒机的参数、价格、型号、原理等信息外，还可为您提供真空上料机、B型旋风脉冲除尘粉碎机、SZG型真空回转干燥机,海光仪器客服电话400-810-0069
