ZGC高压真空型旋转阀

� 适用�?0.8一3kg/cm2系统压力或压差、�/p>

� 设置排气口（正压输送时选用）将叶轮旋转带出的气体通过排气口送至排气装置，提高填充效率、�/p>

� 极小的间隙和特殊的密封装置保持设备的可靠运行、�/p>

� 轴承外置式安装、经久耐用、性能优异、�/p>

� 提供链驱动、直联驱动多种安装方式、�/p>

� 根据需求配置减速机电机、�/p>

� 材质主要有：铸钢、不锈钢系列等、�/p>

ZGC

Drive Mode: Direct Drive/Chain Drive

Main Material: Stainless Steel

Seal type: Gland Packed Seal/Air Purge Gland Packed Seals

Specification:

1. Easy to dismantle and install the rotor for clean out.

2. Outboard Bearing to prevent the cleaning liquid mixed with the oil.

3. The contact space with material both polishing treatment, Easy Cleaning.
