技术参数:
Measuring principle | Infrared absorption |
Measurement Range | 0...1000ppm CO2 0...5.0Vol.-%CO2 0...2500ppm SO2 |
Accuracy | 2% of full range |
Repeatability | 0.5%(at zero 0.5%(at span(/td> |
Baseline noise | 0.5%of range |
Signal response time | t 90<2sec. (at 60 l/h) t 90<1sec. (at 180 l/h) |
Operating Temperature | 0-45ℂ/td> |
Temperature coefficient | <1% of range /10k |
Warm-up time | <3 min.(full specification) |
Output | digital,RS232 analogue?...1,linear |
Input Voltage | 5v,dc |
Power consumption | 8w |
Dimensions | 16010048mm |
Software | PC-operating software vs.RS232 |
主要特点9/strong>
同时测量CO2、SO2两种气体,自身抗干扰设计,适用于碳硫分析领埞/p>
