Semi automated polishing machine (LGP 250-P)

The LGP 250-P is a single purpose apparatus specifically designed for small-scale polishing operations. The robust� simple to use system provides high quality polished chips and thin sections with the minimum capital investment. The disc speed can be varied from 10-600 rpm. Polishing is achieved by means of polishing cloths or magnetic polishing discs. A polishing head with four holders for the chip or thin section production is supplied. The former allows efficient� simultaneous polishing of up to 4 samples. Variable up to 200 gram weights apply a force to hold the sample’s position on the disc. Two sets of four specimen holders are supplied to suit either 30x45mm or 1 x 1.5 inch samples.

Variable speed: 10 to 600 RPM

Specimen size : 30x45mm or 1 x 1.5 inches

Plate diameter: 250 mm

Dimensions: 526 x 589 x 380 mm

Weight: 50 kg

Power supply: 220 VAC - 50/60 Hz

BENEFITS:

* Free vibration at low speeds

* Polishs chips or thin sections

* Easy access for rapid and effortless leaning

* Simultaneous polishing up to four samples
