半导体激光器_生物工程激光器_高功率激光芯牆�/span>
生物光子学、医学成像、生物荧光、共聚焦显微镜�?/span>DNA测序、流式细胞、血液分析、光遗传
拉曼光谱、干涉曝光、全息成像、量子成像、精密测野�/span>
激光种子源、光纤激光器泵浦、固体激光器泵浦、大功率激光器�?/span>3D打印、激光雷辽�/span>
可按应用场景提供定制产品
产品案例
NEWOPTO-405-700(405nm 700mW <0.2mm Beam Size)
NEWOPTO-405-1.4W(405nm 1.4W)
NEWOPTO-405-45-SLM(405nm 45mW <1pm)
NEWOPTO_505_10-50(505nm 10-50mW)
NEWOPTO-633-40-SLM(633nm 40mW <0.1pm)
NEWOPTO-638-20-FC(638nm 20mW PM-fiber)
NEWOPTO-638-30(638nm 30mW <20um Beam Size)
NEWOPTO-638-180(638nm 180mW)
NEWOPTO-915-80-FC(915nm 80mW PM-fiber)
单波长激光器
波长范围９�/span>375nm-1064nm
典型波长９�/span>375nm-405nm-445nm-488nm-505nm-520nm-532nm-561nm-593nm-633nm-638nm-660nm-785nm-808nm-830nm-860nm-915nm-980nm-1030-1064nm
功率９�/span>10mW-2W
光谱线宽(FWHM)�?-2nm�?lt;1pm
功率稳定�?/span>(8小时)�?lt;1% RMS
噪声(20Hz-2MHz)�?lt;0.1% RMS
调制带宽９�/span>10MHz
多波长激光器
自由空间
405nm(130mW)-488nm(40mW)-520nm(40mW)-638nm(130mW)
405nm(120mW)-445nm(70mW)-520nm(40mW)-638nm(130mW)
单模光纤
405nm(50mW)-488nm(20mW)-520nm(20mW)-638nm(50mW)
多模光纤
405nm(100mW)-488nm(25mW)-520nm(30mW)-638nm(100mW)
405nm(100mW)-445nm(30mW)-520nm(30mW)-638nm(100mW)
405nm(100mW)-445nm(30mW)-488nm(25mW)-520nm(30mW)
脉冲激光器
1030nm(150uJ 160kW <0.9ns <1pm)
1030nm(100uJ 35kHz <2ns <1pm)
1030nm(35uJ 35kHz <10ns <1pm)
515nm(25uJ 35kHz <10ns <1pm)
窄线宼�/span>LD
532nm 100mW <0.05nm MM FC/PC.SMA
633nm 10-50mW <100kHz SM TO56.14BF
638nm 35-60mW <100kHz SM TO56.14BF
660nm 50mW <100kHz SM TO56.14BF
785nm 50-500mW <100kHz SM TO56.14BF
785nm 350-600mW <0.07nm MM 14BF
808nm 50-100mW <100kHz SM TO56.14BF
808nm 350-600mW <0.07nm MM 14BF
808nm 2W �?.5nm MM C-mount.14BF
830nm 50-100mW <100kHz SM TO56.14BF
830nm 350-600mW <0.07nm MM 14BF
976nm 220-750mW <100kHz SM 14BF
976nm 4-6W <0.15nm MM 14BF
1053nm 50-300mW <100kHz SM 14BF
1064nm 50-300mW <100kHz SM TO56.14BF
1064nm 350-800mW <0.07nm MM 14BF
单芯牆�/span>LD
630nm 250-400mW
635nm 300-1200mW
650nm 1000mW
660nm 300-2000mW
665nm 300-1600mW
680nm 400-1800mW
690nm 400-1100mW
730nm 2000-4000mW
808nm 1200-10000mW
980nm 1500-5000mW
1064nm 1500-5000mW
多芯牆�/span>LD阵列
660nm 10W
670nm 10W
680nm 12W
690nm 12W
730nm 20W
750nm 20W
760nm 20W
795nm 30W
1064nm 40W

以下功率为自由出光模式，光纤耦合效率70%

Part NumberWavelength(nm)

LDX-3102-445445 ±10 nm

LDX-3350-445445 ±10 nm

LDX-3125-520520 ±10 nm

LDX-2106-622622 ±3 nm

LDX-2205-627627 ±3 nm

LDX-2310-627627 ±3 nm

LDX-2205-630630 ±3 nm

LDX-2410-630630 ±3 nm

LDX-2305-635635 ±3 nm

LDX-2410-635635 ±3 nm

LDX-2615-635635 ±3 nm

LDX-3130-635635 ±3 nm

LDX-2305-645645 ±5 nm

LDX-2410-645645 ±5 nm

LDX-3115-650650 ±5 nm

LDX-2305-660660 ±3 nm

LDX-2710-660660 ±3 nm

LDX-3115-660660 ±3 nm

LDX-3230-660660 ±3 nm

LDX-2305-665665 ±3 nm

LDX-2710-665665 ±3 nm

LDX-3115-665665 ±3 nm

LDX-3230-665665 ±3 nm

LDX-2405-680680 ±3 nm

LDX-2710-680680 ±3 nm

LDX-3115-680680 ±3 nm

LDX-3230-680680 ±3 nm

LDX-3115-685685 ±3 nm

LDX-3230-685685 ±3 nm

LDX-2405-690690 ±3 nm

LDX-2710-690690 ±3 nm

LDX-3115-690690 ±3 nm

LDX-3215-730730 ±3 nm

LDX-3430-730730 ±3 nm

LDX-3110-750750 ±5 nm

LDX-3315-750750 ±5 nm

LDX-3530-750750 ±5 nm

LDX-3315-760760 ±5 nm

LDX 3630-760760 ±5 nm

LDX-3105-780780 ±3 nm

LDX-3210-780780 ±3 nm

LDX-3315-780780 ±3 nm

LDX-3315-795795 ±5 nm

LDX-3105-808808 ±3 nm

LDX-3210-808808 ±3 nm

LDX-3310-808808 ±3 nm

LDX-3415-808808 ±3 nm

LDX-3620-808808 ±3 nm

LDX-3740-808808 ±3 nm

LDX-3820-808808 ±3 nm

LDX-3A20-808808 ±5 nm

LDX-3110-830830 ±5 nm

LDX-3105-860860 ±10 nm

LDX-3110-860860 ±10 nm

LDX-3310-860860 ±10 nm

LDX-3215-860860 ±10 nm

LDX-3320-860860 ±10 nm

LDX-3425-860860 ±10 nm

LDX-3530-860860 ±10 nm

LDX-3535-860860 ±10 nm

LDX-3640-860860 ±10 nm

LDX-3210-885885 ±10 nm

LDX-3515-885885 ±10 nm

LDX-3210-900900 ±5 nm

LDX-3310-915915 ±10 nm

LDX-3515-915915 ±10 nm

LDX-3310-940940 ±10 nm

LDX-3515-940940 ±10 nm

LDX-3105-980980 ±10 nm

LDX-3310-980980 ±10 nm

LDX-3515-980980 ±10 nm

LDX-3105-10641064 ±10 nm

LDX-3310-10641064 ±10 nm

LDX-3515-10641064 ±10 nm

LDX-3205-11201120 ±10 nm

LDX-3310-11201120 ±10 nm

LDX-3515-11201120 ±10 nm

LDX-3105-12101210 ±10 nm

LDX-3210-12101210 ±10 nm

LDX-3115-13501350 ±20 nm

LDX-3310-13501350 ±20 nm

LDX-3510-13501350 ±20 nm

LDX-3209-14501450 ±20 nm

LDX-3509-14701470 ±20 nm

LDX-3715-14701470 ±20 nm

LDX-3820-14701470 ±20 nm

LDX-3925-14701470 ±20 nm

LDX-2803-15501550 ±20 nm

LDX-3105-15501550 ±20 nm

LDX-3110-15501550 ±20 nm

LDX-3210-15501550 ±20 nm

LDX-3209-15501550 ±20 nm

LDX-3309-15501550 ±20 nm

LDX-3518-15501550 ±20 nm

LDX-2815-16201620 ±20 nm

LDX-3110-18501850 ±30 nm

Diode Arrays (Other wavelengths available upon request)

LDX-4119-660660 ±5 nm

LDX-4119-670670 ±5 nm

LDX-4119-680680 ±3 nm

LDX-4119-690690 ±3 nm

LDX-4219-730730 ±5 nm

LDX-4224-750750 ±5 nm

LDX-4219-760760 ±5 nm

LDX-4319-795795 ±5 nm

LDX-4424-10641064 ±10 nm

LDX-4419-10641064 ±10 nm
