仪器简介：

豪迈集团子公司Fiberguide位于美国新泽西州Stirling市。Fiberguide是世界特种光缆、光缆系统和部件方面�?*企业。自�?977年成立以来，Fiberguide定位于“光纤解决方案公司”，在众多应用领域为业界提供***的设计、产品开发、测试和量产服务�

主要应用领域包括�

激光输送系�

光动力治�

眼科

过程控制

紫外�?UV)固化

照明反射

远程遥感(紫外到红�?

烟尘探测

Combined optical/CE arrays

传感

组织脱离-烧灼

血管成形术

牙科

远程照明

Custom GC arrays

压力感应

拉曼散布和光谱学

消散波调整和感应

技术参数：

Multimode� step-index optical fibers offer the most efficient and flexible delivery of high power laser beams. The correct components should be selected for minimizing beam quality degradation and optimum robustness. Smaller fibers tend to produce less degradation to beam quality but the minimum usable fiber size is limited by the quality of the laser beam� focusing optic and the numerical aperture (N.A.) of the fiber. Selection of the appropriate fiber type is an important consideration because the characteristics of the output beam will enhance or degrade the utility of the fiber optic delivered beam for different applications. The other components of the beam delivery system also impact performance: High power handling requires high quality end face surface finish and specially designed connectors that can withstand heating which comes from the absorption of spurious reflections at the fiber end faces. The fiber optic delivery system allows the laser beam to be transmitted in a small� flexible cable and is ideal when the laser beam must be delivered along a complex path or processing requires complicated manipulation of the beam delivery optics.

主要特点９�/strong>

Laser polished fiber ends

High power applications employ a high conductivity copper ferrule in the nose of the connector allowing for greater heat dissipation in event of scattered energy at tip

Heat sink designed to pull heat away from fiber by being thermally and mechanically connected to HP-SMA connector and allows for handling ruggedness� prevent bending of the fiber and maintain beam quality

HP-SMA (High Power) utilizes well type "air gap" ferrule technology that holds the fiber tip in air to eliminate energy absorbing materials at fiber end Cantilevered fiber end is able to accept very high powers

Smaller fiber diameters incorporate a pure fused silica sleeve at the tip to support fiber without addition of energy absorbing materials

Conservatively accommodates peak power densities of 1.3KW/mm2 for CW applications and 5MW/mm2 for pulsed applications

Incorporated into and designed into customer specific applications

Standard core diameters of 200pm to 1500pm

Numerical aperture (N.A.) of 0.12�?.22. 0.26� 0.37 and 0.39

Plastic Clad Silica (PCS)� Hard Clad Silica� Hard Coated Silica/Silica� and Polymer Coated Silica/Silica fiber in standard OH and low OH versions

Wide variety of sheathings/protective jackets
