Out Dia Ø47-Ø120
Width 14-23(AL)

Inner Dia Ø30-Ø75
Width 14-23(BL)

工件支撑方式

Work Piece Support Method

Outer plate
Support roller clamp

Borer plate
Support roller clamp

Outer plate
Support roller clamp

Outer plate
Support roller clamp

工作轴数野�/span>

Number of grinding wheels

2

2

2

2

工件旋转�?/span>

Workpiece Revolution

100~6,000 r.p.m (无级变逞�/span>Stepless Variable)

砂轮摆动周期

Grinding wheel swing Cycle

100~1,200 c.p.m (无级变逞�/span>Stepless Variable)

加工时间Cycle Time

0~60 second (无级变逞�/span>Stepless Variable)

摆动角度Wheel swing angle

0˚~60˚ (无级变逞�/span>Stepless Variable)

砂轮压力

Pressure of grinding wheel forcing axis

粗磨Rough Operation

0-5㎎�/span>/㎟�/span>(无级变逞�/span>Stepless Variable)

研磨Finish Operation

电机ElectricMotors

主轴Work Spindle

1.5kW × 2 (AC Servo)

砂轮摆动Grinding wheel swing

1.5kW × 2 (AC Servo)

分度盗�/span>

Carrier Index

400W × 1 (AC Servo)

槽滑松�/span>Pitch Slide

0.75kW × 2 (AC Servo)

重量Weight (kg)

2,100

2,000

2,300

2,200

选配仵�/span>Optional Accessory

冷却箰�/span>Coolant tank unit
夹具
其它工具Extra set tooling
