管内工作压力 MPa Working pressure in pipe

0.3

0.3

0.3

箱内工作压力 MPa Working pressure in box

0.07

0.07

0.07

箱内真空度 mmHg Vacuum in box

600

600

600

一次装生药量 kg
One-time chemical feeding

60

80

�?20

灭菌时间 min Sterilization time

15�?0

15�?0

15�?0

干燥温度 ℃ Drying temperature

105�?15

105�?15

105�?15

灭菌时间 h Sterilization time

1.5�?

1.5�?

1.5�?

加热面积 m2 Heating area

6

8

12

能耗 kg/h Energy consumption

20

28

40

设备重量 kg Weight

1600

2000

2500

箱内尺寸 mm Size in box

1100×1250×1200

1250×1250×1200

1500×1280×1400

外形尺寸 mm Dimensions

1400×1400×1660

1500×1500×1900

1700×1600×2000
