工作原理 PRINCIPLE:
空气通过过滤器和加热器,进入干燥器顶部的空气分配器,热空气呈螺旋状均匀进入干燥器。料液由料液槽经过滤器由泵送至干燥器顶部的离心雾化器,使料液喷成极小的物状液滴,料液和热空气并流接触,水份迅速蒸发,在短时间内干燥为成品。成品由干燥塔底部和旋风分离器排出,废气由风机抽出排出、/p>
Air is turned into hot air through air filter and heater and enters into hot air distributor at the top of dry chamber and enters into dry chamber spirally and evenly.At the same time liquid of raw material is sent to centrifugal atomizer at the top of dry chamber pumped by pump through filter.In which liquid of raw material atmizes ting droplets.Air and liquid of raw material is dried into finished product in a short time.The finished product is discharged through cyclone scparator at the bottom of drier.The wasred air is exhausted through fan.
设备特点FEATURES OF EQUIOMENT:
干燥速度快,一般只需5-15秒,具有瞬时干燥特点、br/> 物料短时间内完成干燥过程,适应于热敏性物料干燥,能保持物料色、香、味?nbsp;
生产过程简化,操作控制方便,适宜连续控制生产、/p>
产品分散性、流动性、溶解性良好、/p>
Its dry speed is very quick.Ingeneral,it needs 5-15 seconds;It has feature of momentary dry.
Because raw material can be dried momentarily.Especially,it is suitable for drying thermal sensitive raw ,materials.It can maintain color,smell and taste of raw materials.
Its operatiom is stable and simple.Its regulation and control is very convenient.It is easy to realize continuous.controlled production.
The distribution,fluidity and solubility produce are good.
应用范围SCOPE OF APPLICATION:
化学工业: 氟化??、碱性染料颜料、染料中间体、复合肥、甲醛硅酸 催化剂、硫酸剂、氨基酸、白炭黑等、/p>
塑料树脂: AB,ABS乳液、尿醛树脂、酚醛树脂、密??甲醛树脂、聚乙烯、聚氯乙烯等、br/>食品工业: 富脂奶粉、胳朊、可可奶粉、代乳粉、蛋?? 食物及植物: 燕麦、鸡汁、咖啡、速溶茶、调味香料肉、蛋白质、大豆、花生蛋、白质、水解物等糖类:玉米浆、玉米淀粉、葡萄糖、果胶、麦芽糖、山梨酸钾等、/p>
陶瓷:氧化铝、瓷砖材料、氧化镁、滑石等、/p>
CHEMICAL INDUSTRY9/strong>Sodium fluoride(potassium), alkaline dyestuff and pigment, dyestuff intermediate, compound fertilizer, formic silicic acid, catalyst, sulphuric acid agent ,amino acid, white carbon and so on.
PLASTICS AND RESIN:AB、ABS emulsion, uric acid resin, phenolic aldehyde resin, urea-formaldehyde resin, formaldehyde resin, polythene,poly-chloroprene and etc.
FOOD LANDUDTRY:Fatty milk powder, cocoa milk powder, substitute milk power, ege white(yolk) and plant, oats, chicken juice, coffee, instant dissoluble tea, seasoning meat, protein, soybean, peanut protein, hydrolysate and so forth. Sugar corn syrup, corn starch, glucose, pectin, malt sugar, sorbic acid postassium and etc.
CERAMIC:Aluminium oxide, ceramic tile material, magnesium oxide, talcum and so on.
工艺流程 TECHNOLOGICAL PROCESS9/span>
1、过滤器 2、送风 3、加热器(电、蒸气、燃油、煤 4、料 5、供料泵 6、雾化器
7、干燥塔 8、一级收尘器(旋风分离器 9、二级旋风器(旋风分离器、袋滤器(/p>
10、引风机 11、湿式除尘器(水沫除尘器、文丘里(/p>
1、filter 2、fan 3、heater(electic,stream,oil,coal) 4、material slot 5、feding pump
6、spaier 7、dry tower 8、first dust filter 9、second dust filter
10、fan 11、wet dust filter
技术参 TECHNICAL PARAMENTERS9/span>
