仪器简介：

The new QE/IPCE measurement kit allows researchers to measure Quantum efficiency (QE) and Incident Photon to

Charge Carrier Efficiency (IPCE) measurement for solar cells� detectors� or any other photon-to-charge converting device. We

selected the most suitable components for your measurements needs. trusttech is an industry leader in light sources and spectroscopy products.

What are QE and IPCE?

Quantum efficiency (QE) and Incident Photon to Charge Carrier Efficiency (IPCE) indicates the ratio of the number of photons

incident on a solar cell to the number of generated charge carriers. Quantum efficiency is a measure of external efficiency� while IPCE considers the internal efficiency; that is� the photons reflected back from the surface of the cell are not considered.

The QE/IPCE measurements are critical especially during the materials research and cell design stage—because it is of great importance for a device to have an optimal spectral response at the point at which the spectral component of the sunlight is abundant. The system is built by an industry leader in light sources and spectroscopy� so you can rely on our expertise to ensure accuracy of the measurement.

How to Measure QE and IPCE?The key to accurately measure the QE/IPCE of a solar cell is to quantify the intensity of monochromatic light incident to the

device under test and how much current is generated. We provide the most important components� which are the most

common building blocks of a QE/IPCE system that will allow you to quickly set up the experiment.

技术参数：

太阳能电池量子效率QE/ IPCE介绍

太阳能电池量子效率QE (Quantum efficiency)和太阳能电池IPCE(Incident Photon to Charge Carrier Efficiency)表示入射到太阳能电池表面的光子数目与太阳能电池产生的电荷载流子数目比率。太阳能电池量子效率QE (Quantum efficiency)测试是对太阳能电池外部效率的测量，而太阳能电池IPCE(Incident Photon to Charge Carrier Efficiency)测试是对太阳能电池内部效率的测试，也就是说太阳能电池表面反射的光子是不被考虑的�

太阳能电池量子效率QE/ IPCE测试在太阳能电池材料研究和太阳能电池设计中非常关键特殊，因为，对于太阳能电池，在太阳光谱组成分布较强的光谱位置上具有**的光谱响应是极其重要的。该太阳能电池量子效率QE/ IPCE测试设备是以光源和光谱学前沿技术为基础的，所以，您可以信任它的专业测试准确性�

如何测试太阳能电池量子效率QE/ IPCE准确测试太阳能电池量子效率QE/ IPCE的关键是确定照射到待测太阳能电池上的单色光的强度大小和太阳能电池产生的电流大小。我们所提供的都�?重要的太阳能电池量子效率QE/ IPCE测试部件，在这些太阳能电池量子效率QE/ IPCE测试部件的基础上，用户可以很快的完成太阳能电池量子效率QE/ IPCE测试实验、�/p>

主要特点９�/strong>

该系统特点：该系统可覆盖 200nm-1600nm 的波长响应区间。用调制光代替直流光，以减少杂散光、噪声等对测量精度的影响；用锥腔型热释电探测器代替热电堆探测器作为参考探测器，用锁相测量仪器代替直流测量仪器并增加温度控制，以便提高测量系统的灵敏度和光谱响应度标准的平坦程度，进而提高准确度；以双单色仪代替单色仪，大大减少杂散光；同时增加了光谱响应度�?*定标。该系统可以灵活地根据客户需求进行变形，组合。可以完成例如太阳能电池IPCE测试，光电器件光谱响应度分析等实验、�/p>
